Ön Isıtıcı

Teknik Bilgiler

TYPE

GYR-2000

GYR-2001

GYR-2250/D

GYR-2251/D

GYR-2380/D

Main guide pulley dia. (mm)

180

180

250

250

380

Operating frequency (Hz)

4000

4000

300

300

350

Wire dia. (mm)

0.3-1.0

0.3-1.0

0.3-2.5

0.3-2.5

0.2-0.7

Line speed (m/min)

50-2000

30-1000

10-500

10-250

5-100

Preheating temperatures(20°)

0-120

0-200

0-120

0-200

0-150

Max. power (kw)

8.0

8.0

8.0

8.0

8.0

Height of the wire in and out (mm)

1000

1000

1000

1000

1000

Outline (length x thick x high)

500x415x1400

525x420x1290

620x410x1290



TYPE

GYR-1000/D

GYR-1001/D

GYR-1380

Main guide pulley dia. (mm)

250

250

280

Wire dia. (mm)

0.5-3.0

0.5-3.0

0.5-6.0

Line speed (m/min)

0-100

0-60

0-100

Preheating temperatures(20°)

0-120

0-150

0-150

Max. power (kw)

10

10

15

Height of the wire in and out (mm)

1000

1000

1000

Outline (length x thick x high)

525x420x1290

700x500x1290
