Planet 500 - 630

Planet 500 - 630

Teknik Bilgiler
Tech Details
500
630
Single line Diameter of Stranding
08mm
010mm
Range of Stranding
26-83 rpm/min
25-60 rpm/min
Traction Wire -Speed
3.5-32 rpm/min
3.5-32 rpm/min
Range of Stranding Pitch
48-1315mm
58-1280mm
Rotation Range of Taping Head
146-376rpm/min
146-376rpm/min
Pitch Range of Taping Head
10-205mm
10-205mm
Specification of PayOff Reel
PN500
PN630
Specification of TakeUp Reel
01000-2500
01000-3150
Power of Main Motor
45KW(DC)
55KW(DC)
Take Up Moment Motor
60N.M
100N.M
Machine Height
1000MM
l000mmi
